| 加工定制：是 | 类型：汽车故障诊断仪 | 电压：12V |
| 工作温度：0-55℃ | 品牌：samtec | 型号：hsc vci |
| 适用车型：乘用车 |
DoIP协议源码车载以太网诊断协议***13400协议c源码
基于以太网的诊断协议DoIP，DiagnosticoverInternetprotocol(DoIP)stack，符合***13400规范的全部内容，***开发，很多主机厂使用
Bus systems
? 2 x CAN High Speed *** 11898-2, CAN-Specification
2.0A/2.0B (11/29 Bit Identifier), 1x by software switchable to
CAN Fault-Tolerant *** 11898-3
? 2 x K-Line interface according to *** 9141-2 and *** 14230-4,
in addition, any non PC compliant baud rates up to 250 Kbps
? Vehicle Ethernet (DoIP, Diagnosis over IP)
支持如下协议列表：
UDS on CAN (*** 14229-1 on *** 15765-2), *** 15765-2,
TP1.6, TP2.0, SAE-J1939, CCP, XCP CAN, KWP 2000 on CAN
(*** 14230-3 on *** 15765-2), KWP 2000 on K-Line (***
14230-3 on *** 14230-2), CARB, KW71, DoIP1
Highlights
? Time-critical processing of multi-instance protocols
? High data throughput rates
? Support of numerous bus systems
? Gateway functionality between different bus systems
? Supporting MVCI D-PDU standard
? Virtual Machine (VM) for automatic processes
? Wireless LAN (WLAN/WiFi) IEEE 802.11 a/b/g/n/i
? DoIP (Diagnosis over IP)
Interfaces
? USB 2.0 Host and Device
? Fast Ethernet (100MBit/s)
? WLAN (IEEE 802.11 a/b/g/n/i)
Dual Stream with 300 MBit/s (gross data rate)
n-standard for 2.4 GHz and 5 GHz networks
Encryption methods: WEP, WPA and WPA2/PSK,
WPA2/RADIUS
Authentication protocols: EAP-PEAP, EAP-TLS, EAP-TTLS
Radio certification for Europe
? Virtual Access Point functionality
处理器性能：
Performance features
? 32-bit MIPS processor with high-performance core (600 MHz)
? Memory with 32 MB flash and 64 MB SDRAM
? 1 digital input, clamp 15 identification
? 1 analog input, for vehicle voltage monitoring
? Acceleration sensor
? Real time clock (RTC)
? Wakeup on CAN, clamp15, RTC and acceleration sensor
? USB 2.0 Host1) with connection facility for:
USB storage medium
UMTS-modem
GPS receiver
? Capacitive sensor-buttons
? Acoustic alarm
电气信号参数，通过emv电磁兼容测试的can卡，支持选配obd接口
Electrical specifications
? Power consumption<3,6 W
? Supply voltage 7.5 to 36 V
? Current consumption approx. 300 mA at 12 V supply
? Operating temperature 0 ° C to 50 ° C
? Standby mode
? EMV conformance
