16口千兆以太网交换机工业级com服务器

Switch16/Com3，16口千兆以太网交换机，工业级交换机，可定制can接口，定制路由器和防火墙功能，支持COM Server，支持VLAN ，SNMP，DHCP，fixed IP，基于WEB配置，导轨安装，支持网络管理，带SD卡槽

Netintegrator with COM-Server and Ethernet Switch

Gigabit Ethernet Switch with integrated COM Server

16 Ethernet ports via RJ45 sockets, 10BASE-T/100BASE-TX/1000BASE-T

Manageable switch architecture

3 Serial COM ports via DSUB9 which can be set up as virtual ports on the PC and configured as RS-232, RS-422 or RS-485 interfaces

COM-Server with driver software for Windows? 7 and Windows 10

Optional power supply for external device (via COM port connector)

ARM? Cortex?-A8 microcontroller

Web-based configuration and services

VLAN support

SNMP statistics

DHCP client or fixed IP

Switch16/Com3

带有 COM 服务器和以太网交换机的 Netintegrator

带有集成 COM 服务器的千兆以太网交换机

16 个以太网端口，通过 RJ45 插座，10BASE-T/100BASE-TX/1000BASE-T

可管理的交换机架构

3 个通过 DSUB9 的串行 COM 端口，可在 PC 上设置为虚拟端口，并可配置为 RS-232、RS-422 或 RS-485 接口

COM-Server 带有适用于 Windows? 7 和 Windows 10 的驱动程序软件

外部设备的可选电源（通过 COM 端口连接器）

ARM? Cortex?-A8 微控制器

基于 Web 的配置和服务

VLAN 支持

SNMP 统计信息

DHCP客户端或固定IP

DIN Rail Mounted Ethernet Switch

Designed for DIN-EN carrier rail mounting (TS 35)

Robust metal housing

All interfaces accessible via front panel

Easy-to use Configuration Tools

Windows? based configuration tool for serial interfaces

Integrated web server for switch configuration and management

Customization on Request

     ? CAN interface

     ? Router/Firewall functions

DIN 导轨安装式以太网交换机

设计用于 DIN-EN 载轨安装 (TS 35)

坚固的金属外壳

可通过前面板访问所有接口

易于使用的配置工具

基于 Windows? 的串行接口配置工具

用于交换机配置和管理的集成 Web 服务器

按需定制

      ? CAN 接口

      ? 路由器/防火墙功能

Netintegrator

The Netintegrator Switch16/Com3 operates as an Ethernet switch with an integrated COM server. It comes with 16 Ethernet ports via RJ45 sockets and 3 serial interfaces via DSUB9 connectors. All interfaces are easily accessible via connectors in the front panel.

As device server for the COM interfaces and for the configuration of the Ethernet Switch an ARM Cortex-A8 CPU is equipped. The CPU is connected via an additional internal Ethernet port.

COM-Ports

The Switch16/Com3 provides 3 serial interfaces in the network, that can be accessed for example from a PC.

The serial interfaces of the COM ports can be switched by software between the standards RS-232, RS-422 and RS-485. A switchable 24V/1A power supply for external devices is incorporated in one of these serial interfaces.

网络集成商

Netintegrator Switch16/Com3 作为带有集成 COM 服务器的以太网交换机运行。 它带有 16 个通过 RJ45 插座的以太网端口和 3 个通过 DSUB9 连接器的串行接口。 所有接口都可以通过前面板上的连接器轻松访问。

作为 COM 接口和以太网交换机配置的设备服务器，配备了 ARM Cortex-A8 CPU。 CPU 通过一个额外的内部以太网端口连接。

COM 端口

Switch16/Com3 在网络中提供 3 个串行接口，例如可以从 PC 访问。

COM 端口的串行接口可以通过软件在标准 RS-232、RS-422 和 RS-485 之间切换。 用于外部设备的可切换 24V/1A 电源集成在这些串行接口之一中。

microSD Card Slot

A microSDTM card slot is easily accessible from outside. It can be used for firmware updates.

Network Management

The usage of the VLAN (Virtual Local Area Network) improves the security and flexibility of the network. The Switch16/Com3 supports web-based network management for statistics and monitoring.

Software Support

COM-Server with Driver Software for Windows 7 and Windows 10 (32 and 64 bit).

To configure the serial interfaces on the host PC the Switch16/Com3 comes with an easy to-use Windows based tool. For the configuration of the Switch16/Com3 features via the integrated web server a standard web browser can be used.

microSD 卡槽

microSDTM 卡插槽可从外部轻松访问。 它可用于固件更新。

网络管理

VLAN（虚拟局域网）的使用提高了网络的安全性和灵活性。 Switch16/Com3支持基于Web的网络管理，用于统计和监控。

软件支持

COM-Server 带有适用于 Windows 7 和 Windows 10（32 位和 64 位）的驱动程序软件。

为了在主机 PC 上配置串行接口，Switch16/Com3 带有一个易于使用的基于 Windows 的工具。 对于通过集成网络服务器配置 Switch16/Com3 功能，可以使用标准网络浏览器。
